Genuine - Roughhouse 50 - Parts

Owners Manual

• RoughHouse 50, Rattler 50 and Black Cat 50
• Bought a used scooter and it didn't have an owners manual.......here you go

Service Manual

• Essential if you're going to do anything more than basic maintenance
  on your scooter
• Great to have for basic maintenace as well
• Covers the RoughHouse 50, Rattler 50, Rattler 110 and Black Cat

Mirror Set

• Fit all RoughHouse 50's
• Sold only as a complete set

Brake Lever - Right Hand / Front

• Front brake lever for the RoughHouse / BlackCat

Brake Lever - Left Hand / Rear

• Back / rear brake lever - RoughHouse 50 / BlackCat

Pivot Bolt

• Pivot bolt for the Left / Rear lever only (other side coming soon)
• RH and BC

Air Filter

• All years

• Roughhouse 50
• Stock Belt

Fuel Filter

• Fits: RoughHouse 50, Black Cat 50, Rattler 50 and Rattler 110

• NGK is the standard in motorcycle spark plugs and stock on your Genuine Scooter
• Fits the Roughhouse 50 and Buddy 50
• BP7HS

Oil Tank Cap

• RoughHouse 50

CDI

• Can also be referred to as the ECU
• This is a sealed black box that controls spark
• No spark? This could be your issue
• 5 pin (no pin in the middle of the left row)

• If your scooter is not charging the battery while running this could be your problem (troubleshoot per the service manual)
• Roughhouse 50

Magneto Assembly

• Complete assembly with stator and rotor
• Fits: RoughHouse 50

Coil Assembly

• Includes coil, wire, and spark plug cap
• All 50cc Genuine Scooters

• If your engine will not turn over at all and your battery tests OK this could be your issue (troubleshoot properly)
• Includes relay and rubber strap/mount
• Roughhouse 50

• Roughhouse 50
• Activates your brake light and allows the scooter to start

Coil

• RoughHouse 50 and Black Cat 50
• Includes Coil, Wire, and Spark Plug Cap

Ignition / Key Set

• Complete set including Ignition Switch, Gas Cap, and Seat Lock
• Includes two new keys
• Fits the RoughHouse 50
• Choose the correct version for your year -------->

Key Blank

• Rattler and Roughhouse

Replacement Bulb

• For the turn signals above
• Clear
• Sold each

• Roughhouse 50
• Include new springs

• Roughhouse 50, Rattler 50, Buddy 50
• Used in the Variometer and wear over time
• 16mm x 13mm
• Stock 7.5 grams
• Sold as a set of 6

• Roughhouse 50
• Another wear item in your driveline
• Comes complete and pre-assembled as shown

• Roughhouse 50
• Located on the right side of engine
• Keeps air flowing over your engine to keep it cool

• Roughhouse
• This is an updated piston that will work on all years

• Roughhouse
• Sold as a set of two (2)

• Roughhouse

• Roughhouse
• Bearing between crankshaft and wrist pin

• Roughhouse
• A good rule of thumb is - anytime you see these circlips you should replace them (even if you are just replacing your piston rings)

• Roughhouse
• At this price, there's no reason not to replace it when you are doing a rebuild

• Roughhouse
• See above

Top End Rebuild Kit

• Includes everything you need to freshen up your Roughhouse 50
• Includes: Cylinder, Cylinder Head, Piston, Ring Set, Wristpin and Bearing, Circlips, Gaskets and Studs
• Will work on all Roughhouse 50's

Fuel Level Indicator

• Sending unit that fits inside your tank
• If your fuel gauge is not working this could be your problem
• Includes new gasket

• Vacuum operated fuel sending unit
• This unit allows the fuel to flow from your gas tank to carburetor
• Includes filter screen
• Roughhouse 50

Float Bowl O-Ring

• Now available without having to buy the complete float bowl assy
• If you're taking the float bowl off to clean the carb or re-jet its a good idea to have one of these on hand
• RoughHouse

Float Needle

• Is your carb overflowing? This is probably your problem
• RoughHouse

• Roughhouse 50
• Does NOT include pinch bolt

Muffler Cover

• Muffler heat shield
• Does NOT include any bolts, spacers, or washers (we will have them online soon)
  Call us if you need them now

Mounting Hardware - Heat Shields

• Sold as a "kit" as seen in the picture
• 1 "kit" includes 1 each of the following: Heat Resistant Washer, Grommet, Cup Washer, and Screw


Speedo Drive Gear

• Used to drive your speedometer cable off the front wheel
• RH 50

Centerstand Rubber Bumper

• If you hear a lout "clang" when you put your centerstand up check to see if this is missing
• RoughHouse, BlackCat, Rattler, Buddy 50

Centerstand Spring

• Will NOT work on the sidestand (we will have that online soon)
• RoughHouse

Screw

• Common screw used throughout all Genuine scooters
• Part number is: 90110401200
• Check the parts manuals to see where it is used
• 4 x 12 self tapping screw - Black
